Dual Wattage ORION LED Bulkhead (Polo) Fitting CCT
Orion is our wattage & colour switchable 3-CCT 12 & 16W LED bulkhead fitting. with long life and high lumen output. This bulkhead is ideal for internal and external use, in most domestic and commercial applications.
Features
- 3-CCT: Switch between 3000K/4000K/6500K
- Dual Wattage – Switch between 12w and 16w
- 5-Year warranty
- IP65 rated
- Slimline Design
- Easy to install
- Corridor Function Dimming
- Emergency and microwave sensor options available
Available Options
Product Video
| Product Code | Description | Wattage | Colour | Lumens | Datasheet |
|---|---|---|---|---|---|
| 400001 | Orion Bulkhead - Dual Wattage 12/16w - Standard | 12/16W | 3000, 4000, 6500K | 1200/1600lm | Download Datasheet |
| 400002 | Orion Bulkhead - Dual Wattage 12/16w - c/w Microwave Sensor & Corridor Function | 12/16W | 3000, 4000, 6500K | 1200/1600lm | |
| 400003 | Orion Bulkhead - Dual Wattage 12/16w - 3hr Emergency | 12/16W | 3000, 4000, 6500K | 1200/1600lm | |
| 400004 | Orion Bulkhead - Dual Wattage 12/16w - Microwave Sensor, Corridor Function & 3hr Emergency | 12/16W | 3000, 4000, 6500K | 1200/1600lm |
Technical Specification
| LED Type/Qty | SMD2835/144 |
| Lumen Efficacy | 100lm/w |
| Colour Temperature | 3000K/4000K/6500K |
| Luminous Flux | 1200lm/1600lm |
| Colour Index | Ra>80 |
| Dimming Options Available | N/A |
| Input Voltage | AC200-240V/60Hz |
| Max Driver Current | 350mA |
| Working Voltage | DC27-42V |
| IP Rating | IP65 |
| Operating Temperature | -15° - +40°C |
| Lumen Maintenance | L80/B10 @ 50,000hrs |
| Switching Cycles | > 50,000 - 100,000 |
| Power Factor | > 0.9 |
| Warranty | 3-Years |
